universal tool【敏感詞】cutter grinder萬能工具磨床（數控）

made by vollmer,德國孚爾默制造,型號qxd200,  出廠日期year 2009年, 控制系統control

deｓｃｒｉｐｔion描述:

cnc‐controlled machine for the treatment (erosion, grinding, polishing straight surfaces) of pcd

tipped tools up to 250 mm diameter【敏感詞】200 mm length, according to disc‐electrical‐erosion

processes for use in service【敏感詞】in production.

cnc數控磨床（腐蝕、磨削、拋光直線表面），電腐蝕工藝，可生產直徑250mm，長度200mm的pcd刀具。

specifications規格:

控制系統fanuc31i-a5, working range 工作范圍:longitudinal traverse 縱向行程(x- axis) 480 mm, vertical traverse 垂直行程(y-axis) 320 mm, cross traverse 交叉行程(z-axis) 700 mm, rotary table swivelling range 回轉角度(c-axis) +/- 200°, work head spindle 工件座規格iso 50, max. diameter of workpiece 最大工件直徑320 mm, max. length of workpiece for peripheralgrinding 最大磨削工件周邊長度370 mm, max. length of workpiece for face grinding 最大工件端面磨削長度320 mm, length of workpiece for peripheralgrinding 最大磨削工件周邊長度370 mm,precision in linear resolution 線性定位精度0.0001 mm, in radial resolution 圓弧定位精度0.0001°;max. dia. of wheel 最大砂輪直徑200 mm, peak performance grinding spindle 磨削軸峰值功率30 kw,grinding spindle speed 磨削軸速度范圍0 - 10.000 rpm. connected load approx. 裝機容量約35 kw (400 volts/ 50 hz), weight approx.重量約8.400 kg, dimensions 體積w x d x h = 3650 x 2490 x 2510 mm, colour 顏色grey ral 9003 / 7011.

pecifications:

traversing ranges: x‐axis 440 mm, b‐axis +/‐15°, y‐axis 876 mm, z‐axis 420 mm, e‐axis 210°, a‐axis 210°, a‐axis 210°, a‐axis 360°workhead sk50, without magazine operating: workpiece length up to 200 mm, workpiece Ø up

to 250 mm, working length up to 200 mm, workpiece weight max. 15 kg, specification with magazine

行程范圍：x軸（縱向行程）440mm，b軸 +/‐15°，y軸（垂直行程）876mm，z軸（交叉行程）700mm，e軸210°, a軸a‐axis 360°

工作頭 sk50，說明書外的：工件長度可達200mm，工件直徑可達250mm，工作長度可達200mm，最大工件重量可達15公斤，詳見說明書。

operating: workpiece length up to 200 mm, work piece Ø (depending on magazine【敏感詞】number of

tools) up to 250 mm, work piece weight (depending on magazine【敏感詞】number of tools) 5 to 15 kg,

connected load 380v 50hz, colour cover ral 7047 telegrey 4, colour stand ral 7045 telegrey 1, 操作：工件長度可達200mm，工件直徑250mm（取決于說明書和工具數量），工件重量5—15kg（取決于說明書和工具數量），裝機容量380v50hz，顏色：灰色 ral 7045 telegrey 1。

accessories (to be confirmed): 附件（待確認）

total enclosure  全封閉

mist extractor n183

filtering system for dielectric fluid 介質過濾系統

automatic fire extinguishing device kraft und bauer ， kraft und bauer自動滅火系統

standard programs for measurement, erosion etc.標準程序： 測量、腐蝕等

remote service windows xpe  遠程服務windows xpe

automatic diagnostic program of the machine operation status with text statements on screen,

機床操作狀態的自動診斷系統，屏幕有文本說明。

setting of reference points automatically by machine【敏感詞】manually in "teach‐in" mode  機床自動的設置參考點，或在“教授”模式下進行手工設置。

loading device for erosion wheel sets, consisting of a cnc‐controlled swivel arm for the loading【敏感詞】removal of the workpieces from a workpiece magazine 腐蝕砂輪裝載設備，由cnc控制的旋轉臂，可從工件倉中裝卸工件。

discoide workpiece magazine n250 for up to 12 workpieces 可裝12件工件的n250盤狀工具倉

device for automatic dressing of the polishing wheel 拋光砂輪自動自動修整裝置。

automatic probing function for polishing the free surface 拋光任意表面的自動探測功能。

gripper jaws for workpiece automation 自動化工具夾鉗。

6 exchange elements with flange  6個帶凸緣的交換元件。

6 x flushing sets  6個x沖刷裝置。measuring mandre 測量芯棒
